10w mIcro dc gearbox motor for home appliance

FOB Reference Price:Get Latest Price
$3.98 - $4.32 / Pieces | 2 Piece/Pieces metal gear motor for parking lock (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETONM
Model Number:
ET-SGM37-A
Voltage(V):
6~24V
Output Power:
~30W
Usage:
Boat, Car, Electric Bicycle, Home Appliance, Hygine product, vending and bank system
Certification:
CE, ROHS
Type:
Gear Motor
Torque:
0.5-90kg.cm
Construction:
Permanent Magnet
Commutation:
Brush
Protect Feature:
Drip-proof
Speed(RPM):
1-1600rpm
Continuous Current(A):
\
Efficiency:
60%
Supply Ability
Supply Ability:
3000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
carton and foam.
Port
shenzhen and HK
Lead Time :
sample:5-7working days product:20-30 working days



Product Description













1.1  Performance Range:





Type

ET-SGM37-A Gear Motor
Voltage6-24VDC
Norminal Voltage6V, 9V, 12V, 24V
Speed1-1600rpm
Torque0.5-90kg.cm
DiameterO.D37mm
Output Shaft Diameter6mm
Weight500g



















1.2  Drawing:











Remarks:



1.Shaft dimension can be customized;



2.The Voltage can be 6V, 9V ,12V, 24V; The DC Motor's speed is adjustable;



3.The gearbox can be matched with different DC motors.





1.3  A Part of Performance Lists for Reference:





MODELVOLTAGE VDCNO LOADAT MAX EFFICIENCYAT STALL
SPEED R/MINCURRENT ASPEED R/MINCURRENT ATORQUE kg.cmCURRENT ATORQUE kg.cm
ET-SGM37A-2460012600<0.05492<0.251.6<1.28
ET-SGM37A-2420012200<0.05160<0.254.8<1.224
ET-SGM37A-2412012120<0.0591<0.257.5<1.240
ET-SGM37A-24671267<0.0550<0.2513.5<1.272
ET-SGM37A-24401240<0.0529<0.2522<1.2100*
ET-SGM37A-24131213<0.059<0.2540<1.2100*





we can customize the motor accordingly. The output speed and torque are all adjustable.



If you have any technical question about the motor, please feel free to contact us, your inquiry will be welcomed.





1.4   General Instructions Motor Use:





1.  Donot stock dc motor in high temperature and extremely humidity environmetal condition. suggested temperature 10-30 degree and humidity 30-80%.



2. Please do the soldering work in 2 seconds with the solering-iron tip temperature at 340-400 degree.



3.Do not shock or drop the motor onto ground during monting process.



4. Always suggest that prevent motor from stall wich will affect its lifespan.



5.It is necessory to be careful that the adhesive shall not spread into gearbox bearing along shaft.



6. Prevent dc motor from water or liquid. the inflow may cause starting failure.







1.5  Typical Applicatons:





1. Bank System: ATM,



2. Vending Machine: Beverage Vending Machine, Coffee Vending Machine.. ..



3. Security: Door Lock, Safebox,



4.  Sanitary Applications: Towel dispenser, soap dispenser, air freshener dispenser, hand dryer ...



5. Medical Equipments: Automative Blood Press Monitor, Dosing Equipment...



6.Robot and Robot Arm



7. Home Appliance: Kitchen Appliance, TV Lift,  Auto Cleaner, Auto Toilet Lid...



8. Office Products: Printer, Paper Shredder, Label Machine,



Other applications such as bake machine, package machine, warm-light, horse feeders, electric valve.....









Packaging & Shipping



2.1  Packaging



1.Volume50pcs/carton
2.Protective  MeasuresFoam
3.PackageCarton(270mm*250mm*282mm)









2.2  Shipping Ways:





We usually arrang shipment via DHL, Fedex If you have your own Express Account, it's also no problem for us making shipping.









Our Services



3.1  High Precise Measuring Instruments and Devices:







Beside high precise measuring instrument and device, we also have a good engineer team.



If you haveany techncial question on motor, please feel free to contact us, we will be happy to do a favor.









3.2   General Services:



1. Professinal and Quick Reply:  Any inquiry or question will be welcomed, we will reply you within 12 hours with profession.



2. Short Delivery Time:  Samples: 3-5 working days, bulk product: 20-25 working days.



3. Standard Package: Foam and Carton.



4. Conveninet & Low Cost Shippment : DHL, Fedex, UPS, TNT; If you have your own Express Account, it's also OK.



5. Payment Method:  T/T, paypal; choose what is easy and convenniet to you.







Company Information



ETONM MOTOR CO., LIMITED is specially designing and manufacturing Micro DC Motor, especially DC Motor, DC Gear Motor according to customers' needs. With well-trained workers, excellent R&D Team, we output 37 millions sets of Motors.



We have been entering Micro DC Motor industry since the beginning of 2004. Utill now, we have more than 100 series of products. These products are widely used in Home Electronic Appliance, Office Equipment, Health-care Appliance, Sanitation Industry, High-class Toy, Banking System, Electronic and Elcetrical Tools, and Automotive industry and so on...

Now, we are selling motor for customers from more than 30 countires, most of our Motors are designed and manufactured for West European and US cutomers.



4.1   Certifications:
