ETONM Micro 36mm12v Planetary Brushless DC Gear Motor 24V BLDC Motor

FOB Reference Price:Get Latest Price
$16.63 - $19.86 / Pieces | 1000 Piece/Pieces (Min. Order)
Voltage(V):
12V 24V
Output Power:
60W
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETONM
Model Number:
ET-PGM36BL
Usage:
Boat, Car, Electric Bicycle, Home Appliance, robot, robotic kits...
Certification:
CE, ROHS
Type:
Gear Motor
Torque:
~150kg.cm, adjustable
Construction:
Permanent Magnet
Commutation:
Brush
Protect Feature:
Drip-proof
Speed(RPM):
1-1500rpm
Continuous Current(A):
~2A
Efficiency:
65%
Product Name:
12V dc gear motor
Application:
Home Applicance, coffee maker, blinds
Motor type:
Dc Brush Gear Motor
Rated Voltage:
12V 24VDC
Keywords:
High Torque Brushless Dc Motor
Size:
36mm
Shaft:
6mm, 8mm
Speed:
adjustable
noise:
low
Supply Ability
Supply Ability:
6000 Piece/Pieces per Day brushless dc electric motor
Packaging & Delivery
Packaging Details
Planetary DC Gear Motor Packing:
1.30pcs/ctn
2.Carton and Foam
Port
shenzhen and HK
Video Description
Advantages



We know what you concern:



Our Service&Warranty:

1. Within 12 hours reply after recieve your inquiry

2. Excellect& Experience Engineer Team offer proffessional OEM&ODM Service

3. We have over 5 processes control order quality for every order

4. We have professional QA team manage any order feedback until all things solved

Credibility is our company basic principle, no matter what problems you met on our motors, just remember, we are here always.



1. Why choose ET-PGM36BL?

ET-PGM36BLis a kind of High Torque 12VDC Brushless Planetary Gear Motor, its advantages are:

Features:

a. high torque,could up to 60kg.cm

b. strong output shaft/axis, diameter 6.0mm, 8.0mm

c. all metal gears, could be plastic gears also

d. long working life time. we tested in our test room, its motor could run over 5000hours at average continously

e. good noise level. widely used in home&office applications

f. central output shaft/axis







Performance customizable:

a. speed could be customized, from 0.1~1500rpm

b. voltage could be 6VDC, 9VDC, 12VDC, 24VDC

c. shaft length could be changed

d. could be with or without encoder



Below performance table is for reference Only:



MODEL
VOLTAGE
NO LOAD
AT RATED LOAD
OPERATION RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
r/min
mA
r/min
A
kg.cm
ET-PGM36BL-121150
8.0-14.0
12VDC
1150
≤350
961
≤1.7
1.5
ET-PGM36BL-12315
8.0-14.0
12VDC
315
≤350
263
≤1.7
4.0
ET-PGM36BL-12222
8.0-14.0
12VDC
222
≤350
185
≤1.7
6.5
ET-PGM36BL-1284
8.0-14.0
12VDC
84
≤350
70
≤1.7
14.5
ET-PGM36BL-1232
8.0-14.0
12VDC
32
≤350
26
≤1.7
33
ET-PGM36BL-128.3
8.0-14.0
12VDC
8.3
≤350
7
≤1.7
60*
ET-PGM36BL-121.6
8.0-14.0
12VDC
1.6
≤350
1.3
≤1.7
60*
Remarks:
1. Shaft dimension can be customized.
2. The Voltage can be 6V, 12V, 24V; The DC Motor's speed is adjustable.
3. This gearbox can matched with other DC Motor.







Lead Time

Lead time:

Samples: 10 working days normally, 1-3 working days at fast if material stock



Mass production: 30-35 working days normally

Product Uses

Typical Applications:

  • Home&Office Applications: Electric Blinds, Automative Kitchen Cabinet, 3D Printer, Shredder, TV Lift, Table Lift, Smart Heating Control System, Office Machine, Humidifier, BBQ. Pet Feeder
  • Security Industry: Safebox, Smart Lock, Intellegent CCTV System, Access System
  • Robot: Robot Arm, Robot Head, Education Robot, Floor Cleaning Robot;
  • Sanitary Applications: Tissue Dispenser, Towel Dispenser, Smart Toilet Seat, Air Freshener, Soap Dispenser
  • Other uses: Valve, CNC Machine, Vending Machine, Camera Slipping, Medical Equipment.....



Any Interesting or Question, email us directly!





Certifications







Company Information

Etonm Motor is an ISO9001:2008 company, Professionally in R&D and manufacturing Micro DC Motor and Gear Motor. We started our business since 2004, now we have two factories, one is for Mini DC Motor, the other is for Gearbox. Even since the beginning, Etonm have been holding “Mutual-Benefit, Truthful and Innovative” as it core value. Our official website www.etonm.com, you could know about us in detail there.









 Events: EXPO March Alibaba & SIA Fair, Shanghai











Contacts

Whatsapp/Wechat/Tel: +86 137 237 06252

Skype: etmotor2

Website: www.etonm.com
