Electronic Motor 18v dc motor 1000rpm for feeder

FOB Reference Price:Get Latest Price
$12.63 - $14.86 / Pieces | 1000 Piece/Pieces (Min. Order)
Voltage(V):
12V 24V
Output Power:
60W
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETONM
Model Number:
ET-PGM36
Usage:
Boat, Car, Electric Bicycle, Home Appliance, robot, robotic kits...
Certification:
CE, ROHS
Type:
Gear Motor
Torque:
~150kg.cm
Construction:
Permanent Magnet
Commutation:
Brush
Protect Feature:
Drip-proof
Speed(RPM):
1-1500rpm
Continuous Current(A):
~2A
Efficiency:
65%
Product Name:
24vdc gear motor
Supply Ability
Supply Ability:
6000 Piece/Pieces per Day planetary gearhead 12v dc gear motor
Packaging & Delivery
Packaging Details
Planetary DC Gear Motor Packing:
1.30pcs/ctn
2.Carton and Foam
Port
shenzhen and HK
Advantages



We know what you concern:



Our Service&Warranty:

1. Within 12 hours reply after recieve your inquiry

2. Excellect& Experience Engineer Team offer proffessional OEM&ODM Service

3. We have over 5 processes control order quality for every order

4. We have professional QA team manage any order feedback until all things solved

Credibility is our company basic principle, no matter what problems you met on our motors, just remember, we are here always.



1. Why choose ET-PGM36?

ET-PGM36 is a kind of High Torque 12VDC Planetary Gear Motor, its advantages are:

Features:

a. high torque,could up to 60kg.cm

b. strong output shaft/axis, diameter 6.0mm, 8.0mm

c. all metal gears, could be plastic gears also

d. long working life time. we tested in our test room, its motor could run over 1500hours at average continously

e. good noise level. widely used in home&office applications

f. central output shaft/axis







Performance customizable:

a. speed could be customized, from 0.1~1500rpm

b. voltage could be 6VDC, 9VDC, 12VDC, 24VDC

c. shaft length could be changed

d. could be with or without encoder



Below performance table is for reference:



MODEL
VOLTAGE
NO LOAD
AT RATED LOAD
OPERATION RANGE
NOMINAL
SPEED
CURRENT
SPEED
CURRENT
TORQUE
r/min
mA
r/min
A
kg.cm
ET-PGM36-121150
8.0-14.0
12VDC
1150
≤350
961
≤1.7
1.1
ET-PGM36-12315
8.0-14.0
12VDC
315
≤350
263
≤1.7
3.8
ET-PGM36-12222
8.0-14.0
12VDC
222
≤350
185
≤1.7
5.5
ET-PGM36-1284
8.0-14.0
12VDC
84
≤350
70
≤1.7
13
ET-PGM36-1232
8.0-14.0
12VDC
32
≤350
26
≤1.7
31
ET-PGM36-128.3
8.0-14.0
12VDC
8.3
≤350
7
≤1.7
60*
ET-PGM36-121.6
8.0-14.0
12VDC
1.6
≤350
1.3
≤1.7
60*
Remarks:
1. Shaft dimension can be customized.
2. The Voltage can be 6V, 12V, 24V; The DC Motor's speed is adjustable.
3. This gearbox can matched with other DC Motor.









Product Uses

Typical Applications:

  • Home&Office Applications: Electric Blinds, Automative Kitchen Cabinet, 3D Printer, Shredder, TV Lift, Table Lift, Smart Heating Control System, Office Machine, Humidifier, BBQ. Pet Feeder
  • Security Industry: Safebox, Smart Lock, Intellegent CCTV System, Access System
  • Robot: Robot Arm, Robot Head, Education Robot, Floor Cleaning Robot;
  • Sanitary Applications: Tissue Dispenser, Towel Dispenser, Smart Toilet Seat, Air Freshener, Soap Dispenser
  • Other uses: Valve, CNC Machine, Vending Machine, Camera Slipping, Medical Equipment.....
