low noise long lifetime brushless dc gear motor 12v

FOB Reference Price:Get Latest Price
$10.23 - $14.70 / Pieces | 1000 Piece/Pieces (Min. Order)
Voltage(V):
12-24v
Output Power:
7-15w
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ETONM
Model Number:
ET-SGM37BLA
Usage:
Home Appliance, Humidifier, robotics, banking and vending system
Certification:
CE, ROHS
Type:
Gear Motor
Torque:
1-30 KG.CM, high torque
Construction:
Permanent Magnet
Commutation:
Brushless
Protect Feature:
Drip-proof
Speed(RPM):
10-600PM
Continuous Current(A):
-0.3A
Efficiency:
IE 2
Keywords:
low noise
rotation:
CW/CCW
Diameter:
37mm
shaft diameter:
8mm
shaft length:
customized
Noise:
<45dB
Motor type:
brushless motor
Application:
Humidifier, robotics, banking vending system
Supply Ability
Supply Ability:
8000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
200 PCS PER CARTON
Port
Shenzhen;Guangdong;HK
Product Description

Product Application


Our motors are widely used in the following applications and industries: Robotics, Intelligent Sanitary Dispenser and cleaner, Locking and Safe, Electric Valve and Meter, Electric Curtain, Intelligent Cleaner, Automatic Cradle, Bank and Vending Automations, Medical Equipments and Apparatus, Beauty and Health Care, Solar Automation, etc. We have made good achievements in LOW Noise and High Torque regions, and already supplied these solutions to TOP 500 in the world.


Main Features

1) Low noise

2) Japan imported Carbon brush

3) long lifetime

4) oil bearing

5) small dimension with high torque

Certifications
Detailed Images

Founded in year 2004, ETONM MOTOR Is specialized in R&D, manufacturing and selling Mini DC Motor and DC Gear Motor, which includes Spur Gear Motor, Planetary Gear Motor, Worm Gear Motor. These motors are with 1VDC-30VDC, the diameter is from φ8~φ51mm.
ETONM MOTOR always keeps the believes: [Customers First, Technical Customization, Top Quality, Professional Service]. In order to implement these believes, we started two production facilities, one is for Dc Motor, the other is for Gearbox. We introduce fully automatic motor production equipment and inspecting equipments, and more than 150 workers and 15 engineers and technicians. Until now, ETONM is one of the most professional and famous Dc and Gear motor suppliers in China.

Our Service

We can not only provide standard motor but also customzied motor for client.

MARKET

80% motors are exported to overseas market.
