High Torque Flat Reducer spur gear reduction dc 12v gear motor

FOB Reference Price:Get Latest Price
$8.12 - $17.53 / Pieces | 1000 Piece/Pieces (Min. Order)
Voltage(V):
12-24V
Output Power:
\
Lead Time:
Quantity(Pieces) 1 - 60000 >60000
Est. Time(days) 60 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ET
Model Number:
ET-CGM95-G
Usage:
Home Appliance, AUTOMATION
Certification:
CE, ROHS
Type:
Gear Motor
Torque:
1~50kg.cm
Construction:
Permanent Magnet
Commutation:
Brush
Protect Feature:
Drip-proof
Speed(RPM):
1-170rpm
Continuous Current(A):
≤0.28A
Efficiency:
75%
Product Name:
spur gear motor flat gearbox
weight:
400g
shaft diameter:
8mm or custom
shaft shape:
D-shape or O-shape
Gear Material:
metal gear
Rated Voltage:
12V
rated load torque:
1-50kgf.cm
no load speed:
1-170rpm or custom
gearbox size:
95*60mm
motor dia:
35mm
Supply Ability
Supply Ability:
6000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Packing Details : plastic film bags, foam, carton packing.
Port
shenzhen and HK
Lead Time :
Quantity(Pieces) 1 - 60000 >60000
Est. Time(days) 60 To be negotiated
Product Descriptions
                                                          ET-CGM95-G DC motor with flat gearbox
Model
ET-CGM95G
Motor Voltage(VDC)
12v-24v
Gearbox ratio
37, 60, 86, 162, 265, 315, 594, 651, 973, 1059 or Custom
Gearmotor no load speed(rpm)
1rpm - 170rpm, or Custom
Gearmotor rated load speed(rpm)
1-124rpm or Custom
Gearmotor rated load torque(kgf.cm)
1-50kgf.cm
Gearmotor rated current(A)
<0.1A
Gearmotor no load current(A)
<0.28A
Housing material
Stainless Steel
Bearing at output shaft
ball-bearing or  oil-retaining bearing
Certificate
CE,ROHS,ISO
Shaft Shape
D-shaft
Encoder
3PPR, 7PPR, 12PPR
Gear type
Straight gear, or worm gear, or planet construction

 Notice: The above specification is just for reference. The gear motor's gear, shaft, speed, ratio, torque                       and motor type can be customized.

                If you can't find the right motor or feel confused, please contact me. Our engineers will help                           you and evaluate the suitable motor for you.



Products Show

Item Name:   High Torque DC motor With Flat Gearbox

Model Number:  ET-CGM95-G

More Products

ET-PGM36

Planetary gearbox motor

ET-SGM51-B

Round gear motor

ET-WGM58A

Worm Gearbox Motor

ET-CGM95C

Flat gearbox motor

ET-SGM12C

Spur gear motor

ET-SGM37A

Spur gear box motor

Our Company

         Etonm Motor is an ISO9001:2008 company, Professionally in R&D and manufacturing Micro DC Motor and Gear Motor. We started our business since 2004, now we have two factories, one is for Mini DC Motor, the other is for Gearbox. With 13 years experience, we have the perfect team, excellent engineers and modernized production line.

          There are 5 series gear motor and 1 series encoder, over 100 types. They are Round Spur Gear Motor, Right Angle Gear Motor, Planetary Gear MotorFlat Spur Gear Motor, Micro DC Motor and Magnet Encoder. In each series motor, we all have our own strong type.

         ET-WGM58A is very popular used on CNC machine. ET-CGM95C, ET-SGM27A, ET-WGM58C are popular for valve. ET-SGM51B is our another strong product. ET-PGM36, ET-PGM32, ET-PGM28A and ET-PGM28B have a excellent performent, because they are planetary gear motor.

         For round spur gear motor, ET-SGM12C is used on various industry this year. ET-SGM25A, ET-SGM37A, ET-SGM37D2, ET-SGM37E and ET-SGM37F, because their low price and good performance, many clients buy these type motors. ET-CGM95-A has big torque and high rpm, so lots of customers choose this type motor.

         These motors are used on various industries. Home Appliance, Office Equipments, Vending Machine and Bank Equipment, Robotics and Electric Valve, Safe and Security, Sanitary Dispenser. 80% gear motors are exported.


                Porduction Workshop

                 Production Process



Quality control
Certifications
Packing & Shipping

Packing Details  : plastic film bags, foam, carton packing.

Delivery Details : 10-30 days after payment.

1. Special protecting packaging
2. Outer Packing 1
3.  Outer Packing 2
